NEW: HGG ProCAM Lite

If you can imagine it, you can build it!

Create amazing structures in 3D modelling software and simply check the production data including all parameters in HGG’s ProCAM Lite before you send it to your machine to have it cut.

Why ProCAM Lite?

  • Validate your own NC data before fabrication
    Due to 3D visualization, able to correct wrong export errors and also modelling errors.
  • Optimized and effective production process
    Save time in hand-over between your detailing team and production team.
  • Reduce error costs.
    Measure and check critical data using interactive measuring tools
  • Developed by HGG
    The original developer (authors) of TubeNC (.XML) data format for Tekla Structures tubular connections.

3D view DSTV files

Make sure you have a clear view of your cut position, even before it is cut!

When NC (DSTV)-files are exported from a 3D CAD-system it is often desirable to have a 3D view, check and control of the position graphically. This is possible with HGG ProCAM Lite’s DSTV Viewer.

The viewer allows manufacturers of steel structures to have a good communication tool between design and production, to verify the exact content. The different positions can be checked on screen and are shown graphically with all their properties such as holes, cutting angles etc.

A unique feature of the HGG DSTV viewer is, besides the fact that it is free, the new feature called ‘Scribing’. This feature allows users to view the positions of welded parts on the main parts.

Visualize your (Tekla) PCD files

View tubular exported cutting files .PCD or .XML from e.g. Tekla structures

Optimize the effectiveness of your production process. Ensure a smooth and time-saving hand-over between your detailing and production team. Using HGG ProCAM Lite you are able to measure and check critical data, using the interactive measuring tools. Reduce cutting errors and saving material. Use HGG ProCAM Lite for a final check with a 3D visualization.

More about HGG ProCAM Lite

Keep control over your designs and improve the workflow from detailing to production!

HGG’s ProCAM Lite enables you to perform the final production data check without the need for a machine and purchase of viewing software. HGG ProCAM Lite consists of:

  • DSTV Viewer – for beams, square tubes and angle profiles
  • PCD Viewer – for pipes

This unique software tool developed by HGG the developers of the .XML .PCD file format, this allows you to view any .DSTV, .NC, .XML or .PCD file. Even without the use of a machine you can easily perform a final production data check on your files before it’s being cut. All parameters and weld details, such as root opening and markings, can be viewed in HGG’s ProCAM Lite.

Download ProCam Lite
