HGG Cutting Services

Pipe cutting services

Description

With four decades of expertise and a wide array of HGG machinery, we excel in shaping various materials for industries such as infrastructure, crane construction, offshore wind, process industry, and steel construction.

We can cut any desired shape in different material types, offering additional features like miters, saddles, holes, and slots for pipe-to-pipe and pipe-plate connections upon request. Our precise welding preparations, including AWS cuts and tapering, can be executed at angles up to 70°.

Additionally, we can add necessary reference lines and footprint markings on the pipes to meet specific requirements.

Specifications

Width, thickness & tolerances

Width

Min. 25 mm. – Max. 3.020 mm.

Wall thickness

Min. 3 mm. – Max. 100 mm

Tolerances

Endcut and intermediate cut tolerance ± 2 mm, up to and including a thickness of 25 mm.
Endcut and intermediate cut tolerance ± 2 mm plus 0,02 x thickness, from a thickness of 25 mm.
Endcut and intermediate cut tolerance ± 5 mm from a pipe diameter Ø2500mm or conical tube.
Distortion tolerance of a cut ± 2 mm, measured on the inside of the hollow section with respect to the reference line.
Length tolerance is 2x endcut tolerance plus 1/10.000 from length of the pipe

Need help or guidance?

Receive a targeted advice and proposal based on your situation and wishes.

Questions?

Get in touch with our Sales Engineers!

This is why our clients choose us:

Piping

HGG also cuts piping for the installation industry. Complete construction kits are supplied, which saves a lot of manual labor and time.

Large Diameters

For various applications, we cut large diameters of up to 3,000 mm with cutting lengths of up to 180 mm on our SPC-3000.

Holes And Slots

Holes and slots can be cut , for a plate connection for example. To prevent deformation of the material, small dams are used.

Pipe To Pipe Connections

Saddle profiling shapes are used to connect one or multiple pipes with an intersecting pipe.

Reinforcement Plates

In addition to standard pipe cutting, we also cut parts from pipes such as reinforcement plates.CEO

Small Diameters

HGG is also the right place for smaller diameters. These tubes are used for piping, brachings and other applications.CEO

Double Cuts

Profiling double cuts is an effective solution to strengthen the construction and reduce welding volume. We can cut bevels up to 70 degrees.CEO

Interested in our service?

Sales Engineer

Ad Rietveld

Sales Engineer

Bart Meijer

Sales Engineer

Arthur Schouten

Why choose for HGG?

HGG has been cutting profile steel, such as tubes, beams and tubes, for decades with its own developed machines and software.

Reliable partner with 40 years of experience

HGG has been cutting profile steel, such as tubes, beams and tubes, for decades with its own developed machines and software.

Short lead times and a large capacity

With our modern machinery with a large range, HGG takes care of all your profile cutting work within the requested delivery time. Due to our large storage area and machinery, HGG has a large capacity.

The solution for your staff shortage

HGG is active in various industries and takes a lot of manual work off your hands by cutting a wide variety of profiles, making it an extension of your workshop.

Tailor-made for all your profiles

With our advanced software, we cut any desired shape, resulting in less fit time, welding volume and welding time. You will receive a complete construction kit from us, including the desired welding pre-treatment and any markings and fit lines.

Our 4-step process

We take the weight of your shoulders with a simple and clear 4-step process that ensures quick delivery and meets the highest industry standards.

Specialized advice in advance

From our 40 years of 3D profiling experience, we know that every cut can be different. We assist you in the preparation of your project. From engineering, to welding details to optimizing material usage.

Get your quote

Based on your data, preferably in STEP format, we send you a tailored project quote within a few days of your request. If you regularly outsource projects with us, we are eager to take it a step further by establishing a partnership. Assuring you with production capacity and price stability.

Start Work Preparation & Production

After receiving your final models and material we will prepare cutting files using our ProCAM software. Once these files are ready production will be started at our production facility using the machine which suits best to the materials that need to be cut.

Pick-up or get your shipment delivered

After completion of the cutting job, you will receive a message that your materials are ready to be picked up. If you need us to deliver the materials to your site we will make those arrangements.

'Once you've used scribing, there's no doubt you'll use it again.You know that it fits and the chance of failures is almost zero.'

KeesJan Nieuwenhuis – Oostingh Staalbouw BV

Our additional services

Additional Holes and Slots

In addition to the final cuts, we can add holes and slots for various applications. These can also be prepared with the desired welding preparations, such as a ½ V-groove or X/K-groove.

Adding Reference lines and Markings

Our machines can apply reference lines and footprint markings using either a needle or plasma. This not only speeds up fitting time but also ensures higher quality. By incorporating these markings into your engineering plans beforehand, we can replicate them directly in our production process.

Certified for Re-marking

We are certified by Lloyd’s Register Nederland B.V. to transfer markings and numbers and issue inspection reports 3.1 and 3.2 in accordance with EN 10204:2004.

Delivery, Storage & Transport

Materials are usually delivered to us by you or your supplier. We have a large storage area capable of accommodating large-diameter and long-length material. However, we can also arrange transportation for you, ensuring materials are picked up and returned to the desired location. We partner with a transportation provider who offers daily services both within the Netherlands and internationally.

Our accreditations and memberships

Our drawing guidelines

We are flexible with our drawing guidelines; however, we do prefer the options listed below for a speedy process. If you have a different file format or need assistance in preparing your files, feel free to contact our team.

STEP (3D)

We convert STEP files into cutting files with HGG’s ProCAM. Our system reads STEP files in freeform shapes without relying on macros, providing you with design freedom.

DSTV (2D)

No extra post-processor is required because HGG’s ProCAM can import and read data for DSTV (NC/NC1) files. Enriched files, with a 3rd party post-processor are also possible.
