We developed a new macro to mark knuckle areas on profiles. It saves time and manual labor, and it reduces errors.

HGG developed a knuckle marking macro which makes it possible to mark knuckle areas on profiles. The curve data information of knuckles in Aveva are imported into ProCAM. Users are able to verify the knuckle and edit text information. The knuckle macro saves time and manual labor, while it also reduces errors.

Knuckle marking macro now available for PCL

The macro was specially developed for one of our shipbuilding clients, but we thought it would be a good extension of the standard macro package. Every new PCL has it on board.

Do you want to know more about knuckle marking? Contact us for more information or ask us about other developments we can do for you!
